RX IR Series 10-100W_富通尼激光科技（东莞）有限公司

Model	RX-1064-10	RX-1064-30	RX-1064-48	RX-1064-70	RX-1064-100
Wavelength	1064 nm
Average Power @ 1 MHz	10W	30W	48W	70W	100W
Max Pulse Energy	100µJ@50kHz	250µJ@100kHz	420µJ@100kHz	up to 600µJ	~1mJ**
Pulse Width	~10 ps
Repetition Rate†	Single shot to 2MHz (Option to 8MHz)
Pulse to Pulse Stability @ 1 MHz	~1% rms
Spatial Mode	TEM00 M2≤1.3
Beam Pointing Stability	< 20 µrad
Long Term Power Stability (8h±3 °C)	< ±1% rms
Line Frequency	50 to 60 Hz

† Lower rep rates (down to single shot) achieved by selecting higher rep rate pulses with the AOM. Option to 8MHz
‡ Measured at 1064 nm
**In burst mode

未找到相应参数组，请于后台属性模板中添加

Model	RX-1064-10	RX-1064-30	RX-1064-48	RX-1064-70	RX-1064-100
Operating Temperature	15°C to 30°C (59° to 86°F)
Relative Humidity	Non-condensing, 90% Max
Electrical Requirement	100 to 240V AC
Interface	Ethernet / RS 232 / GUI / External TTL Triggering
Warm Up Time	< 15 min
Vibration	Up to 3g
Cooling	Closed Loop Chiller
