OUTPUT CHARACTERISTICS
参数
ENVIRONMENTAL AND UTILITY REQUIREMENTS
DIMENSIONS
特点
| Model | RGL-1064-2 | RGL-1064-4 |
|---|---|---|
| Wavelength | 1064 | |
| Pulse Energy (@1 kHz) | 2 mJ | 4 mJ |
| Average Power (@ 1 kHz) | 2 W | 4 W |
| Beam Divergence | <1 mrad | |
| Pulse Width* | <25 ps | 50 ps (nominal) |
| Repetition Rate | Single Shot to 5 kHz | |
| Spatial Mode | TEM00 M²<1.3 | |
| Long Term Stability (8h±3 °C) | < ±2% | |
| Pulse to Pulse Stability | < 2% rms | |
| Output Beam Diameter | 1.7 mm (nominal) | |
| Beam Ellipticity | < 10% | |
| Beam Point Stability | < 50 urad | |
* Longer pulse width available upon request
